| Batteries | 4 x 6V, 220 amp-hour |
| Charger | 20 amp automatic |
| Brakes | Electric, Friction |
| Capacity – Hydraulic Reservoir | 1.3 gal. / 4.73 L |
| Maximum Ground Bearing Pressure | 90 psi / 6.30 Kg/cm2 |
| Hydraulic Pump | Fixed Displacement Gear |
| Machine Weight | 4635 lb / 2102.40 kg |
| Drive Speed – Platform Elevated | 0.5 mph / 0.80 km/h |
| Drive Speed – Platform Lowered | 2.8 mph / 4.43 km/h |
| Drive System | 24V Electric |
| Gradeability | 25 % |
| Lift Time | 33 sec. |
| Lower Time | 37 sec. |
| Maximum Drive Height | 25 ft 6 in. / 7.77 m |
| Platform Capacity – Extension | 265 lb / 120.20 kg |
| Platform Capacity – Restricted | 800 lb / 362.87 kg |
| Platform Capacity – Unrestricted | 500 lb / 226.80 kg |
| Turning Radius – Inside | 0 in. / 0 m |
| Turning Radius – Outside | 6 ft 9 in. / 2.06 m |
| Ground Clearance | 4 in. / 0.09 m |
| Machine Height | 7 ft 8 in. / 2.33 m |
| Machine Height – Rails Folded | 6 ft 5 in. / 1.94 m |
| Machine Length | 7 ft 7 in. / 2.3 m |
| Machine Width | 2 ft 8 in. / 0.81 m |
| Platform Dimension A | 2 ft 6 in. / 0.76 m |
| Platform Dimension B | 7 ft 7 in. / 2.3 m |
| Platform Extension Length | 3 ft / 0.9 m |
| Platform Height – Lowered | 4 ft 1 in. / 1.23 m |
| Platform Railing Height | 3 ft 7 in. / 1.1 m |
| Tire Size | 16 X 5 in |
| Wheelbase | 6 ft 2 in. / 1.88 m |
| Platform Height | 25 ft 6 in. / 7.77 m |
| Working Height | 31 ft 6 in. / 9.6 m |
