| Generator type | Revolving Field Brushless AC |
|---|---|
| Continuous output, 60Hz, 3 phase | 20kW (25kVA) |
| Continuous output, 1 phase | 15kW (15kVA) [7.5kW(7.5kVA)] |
| Standby output, 3 phase | 22kW (27.5kVA) |
| Voltage, 3 phase (switchable) | 240 [480V] |
| Voltage, 1 phase (switchable) | 120, 139, 240 [277V] |
| Amps, 1 phase, 120V | 62.5A x 2 [31.3A] (zig-zag-w) |
| Amps, 1 phase, 240V | 62.5A [31.3A] (zig-zag-w) |
| Amps, 3 phase, 240V | 60A |
| Amps, 3 phase, 480V | 30A |
| Rated Frequency – Regulation | 60Hz + 0.25% |
| Rated speed, 60Hz | 1800 rpm |
| Sound level, no load at 23 feet | 59 dB(A) |
| Sound level, full load at 23 feet | 62 dB(A) |
| Make, model and type | Isuzu 4LE2T, 4 cylinder |
|---|---|
| Emission certification | US EPA Tier 4 Final |
| Design features | Direct Injection, Turbocharged |
| Displacement | 133 cu. in. (2.179 L) |
| Continuous rated output | 33 hp @ 1800 rpm |
| Starting system | Electric 12V DC |
| Internal fuel capacity | 51.5 gallons (195L) |
| Fuel consumption, full load | 1.6 gal./hr (6.1L/hr) |
| Fuel consumption, 3/4 load | 1.2 gal./hr (4.64L/hr) |
| Fuel consumption, 1/2 load | 0.9 gal./hr (3.6L/hr) |
| Fuel consumption, 1/4 load | 0.7 gal./hr (2.5L/hr) |
| Total coolant capacity | 2.6 gallons (10L) |
| Total oil capacity / oil class | 3.0 gal. (11.5L) |
| Dimensions (L x W x H) | 63” x 33” x 55” (1603 x 850 x 1400mm) |
|---|---|
| Unit dry weight | 1929 lbs (875kg) |
