| Generator type | Revolving Field Brushless AC |
|---|---|
| Continuous output | 11kW (11kVA) |
| Standby output | 12kW (12kVA) |
| Voltage, 1 phase | 120, 240V |
| Amps, 1 phase, 120V | 45.8A x 2 |
| Amps, 1 phase, 240V | 45.8 A |
| Frequency – Regulation | 60Hz ± 0.25% |
| Rated speed, 60 Hz | 1800 rpm |
| Winding | ZigZag-W |
| Power factor / Insulation class | 1.0 / F-class insulation |
| Excitaton / Number of poles | Static (brushless) / 4 poles |
| Sound level, full load | 60 dB(A) |
| Voltage Regulation | 240V±0.5% / 120V±5% |
| Make, model and type | Kubota, D1503 (Tier 4 Final) |
|---|---|
| Displacement | 91.5 cu in (1.499 L) |
| Cylinder | 3 |
| Bore x stroke | 3.27” x 3.64” (83 mm x 92.4 mm) |
| Continuous rated output | 19.5 HP |
| Battery capacity | 12V, 55 Ah |
| Starting motor capacity | 12V, 1.4kW |
| Charging alternator capacity | 12V, 30 Ah |
| Internal fuel capacity | 16 gal (62 L) |
| Fuel consumption, full load | 1.08 gal/hr (4.1 L/hr) |
| Fuel consumption, 3/4 load | 0.81 gal/hr (3.1 L/hr) |
| Fuel consumption, 1/2 load | 0.63 gal/hr (2.4 L/hr) |
| Fuel consumption, 1/4 load | 0.44 gal/hr (1.7 L/hr) |
| Total coolant capacity | 2.30 gal (8.8 L) inculding sub-tank 0.3 gal (1.1 L) |
| Total oil capacity | 1.9 gal (7.3 L) including filter 0.1 gal (0.3 L) |
| Dimensions (L x W x H) | 55” x 28” x 40” (1390 mm x 704 mm x 1012 mm) |
|---|---|
| Unit dry weight | 1246 lbs. (565 kg) |
| Meters and controls | Voltage, frequency, amperage and hour meters; automatic voltage regulator (-15%, +5%). Oil pressure and water temperature indicator; battery charge warning indicator |
